Chapter 48 Mirror Commands
Ethernet Switch CLI Reference Guide
190
48.1 Command Summary
The following section lists the commands for this feature.
Table 127 mirror Command Summary
COMMAND DESCRIPTION M P
mirror-port Enables port mirroring on the Switch. C 13
mirror-port <port-num> Specifies the monitor port (the port to which traffic flow is
copied) for port mirroring.
C13
no mirror-port Disables port mirroring on the Switch. C 13
no mirror-port <port-num> Removes the specified monitor port.
port-num: in a modular switch, enter the port number
preceded by a slot number and backslash (/). For example, 3/
11 indicates port 11 on the card in the third slot.
C13
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s).
port-list: in a modular switch, enter the port number
preceded by a slot number and backslash (/). For example, 3/
11 indicates port 11 on the card in the third slot. Use a comma
(,) to separate individual ports or a desh (-) to indicates a
range of ports. For example, “3/11,4/5” or “3/7-3/9”.
C13
mirror Enables port mirroring in the interface. C 13
mirror dir
<ingress|egress|both>
Enables port mirroring for incoming (ingress), outgoing
(egress) or both incoming and outgoing (both) traffic.
C13
no mirror Disables port mirroring on the port(s). C 13
Table 128 mirror-filter Command Summary
COMMAND DESCRIPTION M P
mirror-filter egress mac <mac-
addr>
Copies outgoing frames with the specified source or
destination MAC address from mirrored ports to the monitor
port.
C13
mirror-filter egress type
<all|dest|src>
This command works with the previous command,
mirror-filter egress mac.
all: Specifies that the Switch should copy all outgoing traffic
from mirrored ports.
dest: Specifies that the Switch should copy all outgoing
traffic with the specified destination MAC address from
mirrored ports.
src: Specifies that the Switch should copy outgoing traffic
with the specified source MAC address from mirrored ports.
C13
mirror-filter ingress mac <mac-
addr>
Copies incoming frames matching with the specified source
or destination MAC address from mirrored ports to the
monitor port.
C13
mirror-filter ingress type
<all|dest|src>
This command works with the previous command,
mirror-filter ingress mac.
all: Specifies that the Switch should copy all outgoing traffic
from mirrored ports.
dest: Specifies that the Switch should copy all incoming
traffic with the specified destination MAC address from
mirrored ports.
src: Specifies that the Switch should copy all incoming traffic
with the specified source MAC address from mirrored ports.
C13
show mirror Displays mirror settings of the Switch. E 3
