Chapter 37 Link Layer Discovery Protocol (LLDP) Commands
Ethernet Switch CLI Reference Guide
167
The following table describes the labels in this screen.
This example shows local Switch (the Switch you’re accessing) LLDP information
The following table describes the labels in this screen.
Table 110 LLDP statistics on a port
LABEL DESCRIPTION
Local Port This displays the port number with these LLDP statistics.
Frames Discarded This displays the number of discarded frames on this port.
Frames Invalid This displays the number of invalid frames on this port.
Frames Received This displays the number of frames received on this port.
Frames Sent This displays the number of frames sent on this port.
TLVs Unrecognized This displays the number of unrecognized TLVS on this port.
TLVs Discarded This displays the number of discarded TLVs on this port.
Neighbor Ageouts This displays the number of neighbors with expired TTLs on this port.
sysname# show lldp info local
LLDP Global Local Device Information:
Chassis ID Subtype: mac-address
Chassis ID: 00:19:cb:00:00:02
System Name: sysname
System Description: V4.00(AAEW.0)b7 | 12/11/2012
System Capabilities Supported: Bridge
System Capabilities Enabled: Bridge
Management Address :
Management Address Subtype: ipv4 / all-802
Interface Number Subtype: unknown
Interface Number: 0
Object Identifier: 0
sysname#
Table 111 Local LLDP Information
LABEL DESCRIPTION
LLDP Global Local
Device Information
This contans the chassis ID subtype, chassis ID, and system name.
System Description This shows the firmware version number and date released.
System Capabilities
Supported
This shows what functionality the Switch supports.
System Capabilities
Enabled
This shows what functionality is enabled on the Switch.
Management Address This contains the management address subtype, interface number
subtype, interface number, and object identifier.
