Zyxel XS3700-24 [78/371] Display commands
![Zyxel XS3700-24 [78/371] Display commands](/views2/1168986/page78/bg4e.png)
Ethernet Switch CLI Reference Guide
78
CHAPTER 18
Display Commands
Use these commands to display configuration information.
18.1 Command Summary
The following section lists the commands for this feature.
Table 58 display Command Summary
COMMAND DESCRIPTION M P
display user <[system][snmp]> Displays all or specific user account information in the
configuration file.
system: Displays system account information, such as
admin, enable or login username and password.
snmp: Displays SNMP user account information.
C14
no display user <[system][snmp]> Hide all or specific user account information in the
configuration file.
C14
display aaa
<[authentication][authorization][s
erver]>
Displays all or specific AAA information in the
configuration file.
authentication: Displays authentication information in
the configuration file.
authorization: Displays authorization information in
the configuration file.
server: Displays authentication server information in the
configuration file.
C14
no display aaa
<[authentication][authorization][s
erver]>
Hide all or specific AAA information in the configuration
file.
C14
