Zyxel XS3700-24 [125/371] Ethernet switch cli reference guide
![Zyxel XS3700-24 [125/371] Ethernet switch cli reference guide](/views2/1168986/page125/bg7d.png)
Chapter 31 Interface Commands
Ethernet Switch CLI Reference Guide
125
This example configures ports 1, 3, 4, and 5 in the following ways:
1 Sets the IEEE 802.1p quality of service priority to four (4).
2 Sets the name “Test”.
3 Sets the speed to 100 Mbps in half duplex mode.
This example configures ports 1-5 in the following ways:
1 Sets the default port VID to 200.
2 Sets these ports to accept only tagged frames.
128-255 This field shows the number of packets (including bad packets) received
that were between 128 and 255 octets in length.
256-511 This field shows the number of packets (including bad packets) received
that were between 256 and 511 octets in length.
512-1023 This field shows the number of packets (including bad packets) received
that were between 512 and 1023 octets in length.
1024-1518 This field shows the number of packets (including bad packets) received
that were between 1024 and 1518 octets in length.
Giant This field shows the number of packets (including bad packets) received
that were between 1519 octets and the maximum frame size.
The maximum frame size varies depending on your switch model. See
Product Specification chapter in your User’s Guide.
sysname(config)# interface port-channel 1,3-5
sysname(config-interface)# qos priority 4
sysname(config-interface)# name Test
sysname(config-interface)# speed-duplex 100-half
sysname (config)# interface port-channel 1-5
sysname (config-interface)# pvid 200
sysname (config-interface)# frame-type tagged
Table 84 show interfaces (continued)
LABEL DESCRIPTION
