Chapter 29 IGMP Snooping Commands
Ethernet Switch CLI Reference Guide
115
igmp-snooping vlan <vlan-id>
[name <name>]
Specifies which VLANs to perform IGMP snooping on if the
mode is fixed. Optionally, sets a name for the multicast
VLAN.
name: 1-32 printable characters; spaces are allowed if you
put the string in double quotation marks (“).
C13
no igmp-snooping vlan <vlan-id> Removes IGMP snooping configuration on the specified
VLAN if the mode is fixed.
C13
Table 80 interface igmp Command Summary
COMMAND DESCRIPTION M P
show interfaces config <port-
list> igmp-group-limited
Displays the group limits for IGMP snooping. E 3
show interfaces config <port-
list> igmp-immediate-leave
Displays the immediate leave settings for IGMP snooping. E 3
show interfaces config <port-
list> igmp-query-mode
Displays the IGMP query mode for the specified port(s). E 3
show interfaces config <port-
list> igmp-snooping filtering
Displays the name(s) of the IGMP filtering profiles used for
the specified port(s).
E3
show interfaces config <port-
list> igmp-snooping group-
limited
Displays whether the group limit is enabled and the maximum
number of the multicast groups the specified port(s) is
allowed to join.
E3
show interfaces config <port-
list> igmp-snooping leave-mode
Displays the IGMP leave mode of the specified port(s). E 3
show interfaces config <port-
list> igmp-snooping query-mode
Displays the IGMP querier mode of the specified port(s). E 3
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s). C 13
igmp-snooping
authentication
Enables IGMP snooping authentication on the port(s).
When a multicast host (connected to the specified ports)
sends a message to join a multicast group, the Switch sends
an access request (that conatins the host identification
information) to an AAA server before forwarding the join
message to the multicast router/switch. The Switch learns the
multicast group membership when the AAA server returns an
access-accept. If the AAA server returns an access-reject,
the Switch will not learn the multicast group membership, nor
process the packet further. If the multicast group and port has
already been learned, the Switch will not do the
authentication again.
C13
igmp-snooping fast-leave-
timeout <200-6348800>
Set the IGMP snooping fast leave timeout (in miliseconds) the
Switch uses to update the forwarding table for the port(s).
This defines how many seconds the Switch waits for an IGMP
report before removing an IGMP snooping membership entry
when an IGMP leave message is received on this port from a
host.
C13
igmp-snooping filtering
profile <name>
Assigns the specified IGMP filtering profile to the port(s). If
IGMP filtering is enabled on the Switch, the port(s) can only
join the multicast groups in the specified profile.
C13
igmp-snooping group-limited Enables the group limiting feature for IGMP snooping. You
must enable IGMP snooping as well.
C13
Table 79 igmp-snooping vlan Command Summary (continued)
COMMAND DESCRIPTION M P
