Chapter 14 Data Center Bridging Commands
Ethernet Switch CLI Reference Guide
66
14.2.6 Application Priority Command Examples
In the following example, all FCoE traffic on the switch is assigned with priority 3.
Application priority can then be used in conjunction with ETS and PFC as shown in the
following examples.
This is an application priority command example with PFC.
This is an application priority command example with ETS.
• Default traffic class 0 with strict priority for priorities 0, 1, 2, 6, 7
• Traffic class 3 (for legacy Ethernet traffic): Guarantee bandwidth 40% for priority 4, 5
• Traffic class 4 (for FCoE traffic): Guarantee bandwidth 60% for priority 3
• Unicast to Non-Unicast weight ratio is 100:100
switchA# configure
switchA(config)# lldp dcbx application ether-type fcoe priority 3
switchA(config)# interface port-channel 5
switchA(config-interface)# priority-flow-control
switchA(config-interface)# priority-flow-control priority 3
switchB(config)# interface port-channel 6
switchB(config-interface)# priority-flow-control
switchB(config-interface)# priority-flow-control priority 3
Table 48 ETS Example 2 Traffic Classes
PRIORITY TRAFFIC CLASS ID NAME
0 0 Default
1 0 Default
2 0 Default
34 FCoE
4 3 Ethernet
5 3 Ethernet
6 0 Default
7 0 Default
sysname# configure
sysname(config)# traffic-class 3 scheduler ets 40 name ethernet
sysname (config)# traffic-class 4 scheduler ets 60 name fcoe
sysname (config)# interface port-channel 6
sysname (config-interface)# ets
sysname (config-interface)# ets traffic-class binding 0 0 0 4 3 3 0 0
sysname (config-interface)# unicast-nonunicast-weight 100 100
