Chapter 33 IP Commands
Ethernet Switch CLI Reference Guide
128
33.2 Command Examples
This example shows the TCP statistics and listener ports. See RFC 1213 for more information.
The following table describes the labels in this screen.
show ip udp Displays IP UDP information. E 3
kick tcp <session id> Disconnects the specified TCP session.
session id: Display the session id by running the show
ip tcp command. See Section 33.2 on page 128 for an
example.
E13
Table 87 tcp and udp Command Summary (continued)
COMMAND DESCRIPTION M P
sysname# show ip tcp
( 1)tcpRtoAlgorithm 4 ( 2)tcpRtoMin 0
( 3)tcpRtoMax 4294967295 ( 4)tcpMaxConn 4294967295
( 5)tcpActiveOpens 2 ( 6)tcpPassiveOpens 188
( 7)tcpAttemptFails 3 ( 8)tcpEstabResets 25
( 9)tcpCurrEstab 1 (10)tcpInSegs 4025
(11)tcpOutSegs 5453 (12)tcpRetransSegs 64
(14)tcpInErrs 0 (15)tcpOutRsts 0
&TCB Rcv-Q Snd-Q Rcv-Wnd Snd-Wnd Local socket Remote socket
State
80d60868 0 620 128 63907 172.16.37.206:23 172.16.5.15:1510
Estab
80d535a0 0 0 128 1 0.0.0.0:23 0.0.0.0:0
Listen (S)
80d536bc 0 0 16384 1 0.0.0.0:80 0.0.0.0:0
Listen (S)
80d5f6a8 0 0 22400 1 0.0.0.0:21 0.0.0.0:0
Listen
80d5440c 0 0 128 1 0.0.0.0:22 0.0.0.0:0
Listen
80d541d4 0 0 22400 1 0.0.0.0:443 0.0.0.0:0
Listen (S)
Table 88 show ip tcp
LABEL DESCRIPTION
tcpRtoAlgorithm This field displays the algorithm used to determine the timeout value that is
used for retransmitting unacknowledged octets.
tcpRtoMin This field displays the minimum timeout (in milliseconds) permitted by a
TCP implementation for the retransmission timeout. More refined
semantics for objects of this type depend upon the algorithm used to
determine the retransmission timeout. In particular, when the timeout
algorithm is rsre(3), an object of this type has the semantics of the
LBOUND quantity described in RFC 793.
tcpRtoMax This field displays the maximum timeout (in milliseconds) permitted by a
TCP implementation for the retransmission timeout. More refined
semantics for objects of this type depend upon the algorithm used to
determine the retransmission timeout. In particular, when the timeout
algorithm is rsre(3), an object of this type has the semantics of the
UBOUND quantity described in RFC 793.
