Zyxel XS3700-24 [44/371] Command summary
![Zyxel XS3700-24 [44/371] Command summary](/views2/1168986/page44/bg2c.png)
Chapter 10 CFM Commands
Ethernet Switch CLI Reference Guide
44
10.4 Command Summary
The following section lists the commands for this feature.
Table 29 CFM Command Summary
COMMAND DESCRIPTION M P
clear ethernet cfm linktrace Clears the link trace database. E 13
clear ethernet cfm mep-ccmdb Clears the MEP CCM database. E 13
clear ethernet cfm mip-ccmdb Clears the MIP CCM database. E 13
clear ethernet cfm mep-defects Clears the MEP-defects database. E 13
ethernet cfm Enables CFM on the Switch. C 13
ethernet cfm loopback remote-mep
<mep-id> mep <mep-id> ma <ma-index>
md <md-index> [size <0-1500>][count
<1-1024>]
Specifies the remote MEP ID, local MEP ID, MA index
and MD index to perform a loopback test.
This enables the MEP port (with the specified MEP ID) in
a specified CFM domain to send the LBMs (Loop Back
Messages) to a specified remote end point.
You can also define the packet size (from 0 to 1500
bytes) and how many times the Switch sends the LBMs.
E13
ethernet cfm loopback mac <mac-
address> mep <mep-id> ma <ma-index>
md <md-index> [size <0-1500>][count
<1-1024>]
Specifies the destination MAC address, local MEP ID,
MA index and MD index to perform a loopback test.
This enables the MEP port (with the specified MEP ID) in
a specified CFM domain to send the LBMs (Loop Back
Messages) to a specified remote end point.
You can also define the packet size (from 0 to 1500
bytes) and how many times the Switch sends the LBMs.
E13
ethernet cfm linktrace remote-mep
<mep-id> mep <mep-id> ma <ma-index>
md <md-index> [mip-ccmdb][[ttl
<ttl>]
Specifies the remote MEP ID, local MEP ID, MA index
and MD index to perform a link trace test.
This enables the MEP port (with the specified MEP ID) in
a specified CFM domain to send the LTMs (Link Trace
Messages) to a specified remote end point.
mip-ccmdb: Specifies the MIP CCM DB, a database that
stores information (tuples of {Port, VID, MAC address})
about MEPs in the MD when receiving CCMs. The MIP
CCM DB is used for fault isolation, such as link trace and
loop back. An entry can remains in the MIP CCM DB for
at least 24 hours.
ttl: This is the time-to-live value (the number of
transmissions, 64 hops by default). Sets this to stop a
test once it exceeds the time duration without receiving
any response.
E13
ethernet cfm linktrace mac <mac-
address> mep <mep-id> ma <ma-index>
md <md-index> [mip-ccmdb][[ttl
<ttl
>]
Specifies the destination MAC address, local MEP ID,
MA index and MD index to perform a link trace test.
This enables the MEP port (with the specified MEP ID) in
a specified CFM domain to send the LTMs (Link Trace
Messages) to a specified remote end point.
mip-ccmdb: Specifies the MIP CCM DB, a database that
stores information (tuples of {Port, VID, MAC address})
about MEPs in the MD when receiving CCMs. The MIP
CCM DB is used for fault isolation, such as link trace and
loop back. An entry can remains in the MIP CCM DB for
at least 24 hours.
ttl: This is the time-to-live value (the number of
transmissions, 64 hops by default). Sets this to stop a
test once it exceeds the time duration without receiving
any response.
E13
