Ethernet Switch CLI Reference Guide
320
CHAPTER 91
Voice VLAN Commands
Use these commands to set up Voice VLAN on the Switch.
91.1 Voice VLAN Overview
Voice VLAN ensures that the sound quality of an IP phone is preserved from deteriorating
when the data traffic on the Switch ports is high. It groups the voice traffic with defined
priority into an assigned VLAN which enables the separation of voice and data traffic coming
onto the Switch port.
You can set priority level to the Voice VLAN and add MAC address of IP phones from
specific manufacturers by using its ID from the Organizationally Unique Identifiers (OUI).
See below commands and examples to set up the Voice VLAN.
91.2 Command Summary
The following section lists the commands for this feature.
Table 203 Voice VLAN Command Summary
COMMAND DESCRIPTION M P
voice-vlan <vlan-id> Sets the Voice VLAN ID. C 13
voice-vlan priority <0-7> Sets the Voice VLAN priority level. C 13
voice-vlan oui <mac-addr> mask
<mask-addr> description
<description>
Sets the Voice VLAN device’s OUI address, mask address
and device manufacturer description..
C13
no voice-vlan Disables Voice VLAN configuration. C 13
no voice-vlan oui <mac-addr>
mask <mask-addr>
Removes the OUI from the Voice VLAN. C 13
show voice-vlan Show Voice VLAN status. E 3
