Chapter 35 IPv6 Commands
Ethernet Switch CLI Reference Guide
143
Table 99 ipv6 icmp and ping6 Command Summary
COMMAND DESCRIPTION M P
ipv6 icmp error-interval <0-
2147483647> [bucket-size <1-200>]
Sets the average transmission rate of ICMPv6 error
messages the Switch generates, such as Destination
Unreachable message, Packet Too Big message, Time
Exceeded message and Parameter Problem message.
error-interval: specifies a time period (in
milliseconds) during which packets of up to the bucket
size (10 by default) can be transmitted. 0 means no limit.
Note: The Switch applies the time interval in
increments of 10. For example, if you set
a time interval from 1280 to 1289
milliseconds, the Switch uses the time
interval of 1280 milliseconds.
bucket-size: Defines the maximum number of packets
which are allowed to transmit in a given time interval. If
the bucket is full, subsequent error messages are
suppressed.
C13
ping6 <ipv6-address> <[-i
<interface-type> <interface-
number>] [-t] [-l <1-1452>] [-n <1-
65535>] [-s <ipv6-address>]
Sends IPv6 ping packets to the specified Ethernet device.
interface-type: the Switch supports only the VLAN
interface type at the time of writing.
interface-number: The VLAN ID to which the Ethernet
device belongs.
-l <1-1452>: Specifies the size of the ping packet.
-t: Sends ping packets to the Ethernet device indefinitely.
Press [CTRL]+C to terminate the Ping process.
-n <1-65535>: Specifies how many times the Switch
sends the ping packets.
-s <ipv6-address>: Specifies the source IPv6
address of the pin packets.
E0
show ipv6 mtu The Switch uses Path MTU Discovery to discover Path
MTU (PMTU), that is, the minimum link MTU of all the
links in a path to the destination. If the Switch receives an
ICMPv6 Packet Too Big error message after sending a
packet, it adjusts the next packet size according to the
suggested MTU in the error message.
Displays IPv6 path MTU information on the Switch.
E3
Table 100 ipv6 mld snooping-proxy Command Summary
COMMAND DESCRIPTION M P
clear ipv6 mld snooping-proxy
statistics all
Removes all MLD snooping-proxy statistics of the Switch. E 13
clear ipv6 mld snooping-proxy
statistics port
Removes the MLD snooping-proxy statistics of the port(s). E 13
clear ipv6 mld snooping-proxy
statistics system
Removes the MLD snooping-proxy statistics of the
Switch.
E13
clear ipv6 mld snooping-proxy
statistics vlan
Removes the MLD snooping-proxy statistics of the
multicast VLAN(s).
E13
interface port-channel <port-list> Enters config-interface mode for the specified port(s). C 13
ipv6 mld snooping-proxy
filtering group-limited
Enables multicast group limits for MLD snooping-proxy. C 13
