Zyxel XS3700-24 [236/371] Chapter 61 private vlan commands
![Zyxel XS3700-24 [236/371] Chapter 61 private vlan commands](/views2/1168986/page236/bgec.png)
Chapter 61 Private VLAN Commands
Ethernet Switch CLI Reference Guide
236
Primary PVLAN 100 is then mapped to port 2 on the Switch and outgoing frames from port 2 will be
tagged
.
sysname# configure
sysname(config)# vlan 100
sysname(config-vlan)# private-vlan primary
sysname(config-vlan)# exit
sysname(config)# vlan 101
sysname(config-vlan)# private-vlan community
sysname(config-vlan)# exit
sysname(config)# vlan 102
sysname(config-vlan)# private-vlan isolated
sysname(config-vlan)# exit
sysname(config)# vlan 100
sysname(config-vlan)# private-vlan association 101,102
sysname(config-vlan)# exit
sysname(config)# exit
sysname# show vlan private-vlan
Private Vlan:
Primary Secondary Type Ports
------- --------- ---------- --------------------
100 Primary
100 102 Isolated
100 101 Community
sysname#
sysname# configure
sysname(config)# interface port-channel 2
sysname(config-interface)# private-vlan mode promiscuous association 100
-->
dot1q tagged
sysname(config-interface)#exit
sysname(config)#
