![Zyxel XS3700-24 [75/371] Command examples](/views2/1168986/page75/bg4b.png)
Chapter 16 DHCP Snooping & DHCP VLAN Commands
Ethernet Switch CLI Reference Guide
75
The following table describes the dhcp-vlan commands.
16.2 Command Examples
This example:
• Enables DHCP snooping Switch.
• Sets up an external DHCP snooping database on a network server with IP address
172.16.37.17.
• Enables DHCP snooping on VLANs 1,2,3,200 and 300.
• Sets the Switch to add the slot number, port number and VLAN ID to DHCP requests that
it broadcasts to the DHCP VLAN.
• Sets ports 1 - 5 as DHCP snooping trusted ports.
• Sets the maximum number of DHCP packets that can be received on ports 1 - 5 to 100
packets per second.
• Configures a DHCP VLAN with a VLAN ID 300.
Table 56 dhcp-vlan Command Summary
COMMAND DESCRIPTION M P
dhcp dhcp-vlan <vlan-id> Specifies the VLAN ID of the DHCP VLAN. C 13
no dhcp dhcp-vlan Disables DHCP VLAN on the Switch. C 13
