Chapter 28 IGMP and Multicasting Commands
Ethernet Switch CLI Reference Guide
111
• Configures the IP interface 172.16.1.1 with subnet mask 255.255.255.0 to route IGMP
version 3 packets.
sysname(config)# router igmp
sysname(config-igmp)# non-querier
sysname(config-igmp)# unknown-multicast-frame flooding
sysname(config-igmp)# exit
sysname(config)# interface route-domain 172.16.1.1/24
sysname(config-if)# ip igmp v3
