4. Motion Control Instruction
4-104 DVP-MC operating manual
Parameter name Explanation Data type
Available
device
output 1
Indicates the execution stage of electronic cam
operation. When the electronic cam operation
reaches or exceeds the stage set by Percent 1,
output 1 remain high for one full cycle.
BOOL M,Q
output 2
Indicates the execution stage of electronic cam
operation. When the electronic cam operation
reaches or exceeds the stage set by Percent 2,
output 2 remains high for one full cycle.
BOOL M,Q
output 3
Indicates the execution stage of electronic cam
operation. When the electronic cam operation
reaches or exceeds the stage set by Percent 3,
output 3 remains high for one full cycle.
BOOL M,Q
output 4
Indicates the execution stage of electronic cam
operation. When the electronic cam operation
reaches or exceeds the stage set by Percent 4,
output 4 remains high for one full cycle.
BOOL M,Q
output 5
Indicates the execution stage of electronic cam
operation. When the electronic cam operation
reaches or exceeds the stage set by Percent 5,
output 5 remains high for one full cycle.
BOOL M,Q
output 6
Indicates the execution stage of electronic cam
operation. When the electronic cam operation
reaches or exceeds the stage set by Percent 6,
output 6 remains high for one full cycle.
BOOL M,Q
output 7
Indicates the execution stage of electronic cam
operation. When the electronic cam operation
reaches or exceeds the stage set by Percent 7,
output 7 remains high for one full cycle.
BOOL M,Q
output 8
Indicates the execution stage of electronic cam
operation. When the electronic cam operation
reaches or exceeds the stage set by Percent 8,
output 8 remains high for one full cycle.
BOOL M,Q
Notes:
1. A full electronic cam cycle is 100%.
2. DMC_CAM Switch can be used only when the electronic cam relationship is established successfully.
3. The V1.06 or above firmware supports this function
Program example
Here is an introduction to the use of DMC_CamSwitch instruction. The electronic cam curve for this
example is shown as below with a cam cycle of 20,000.
