Appendix C
C-24 DVP-MC operating manual
Special
D
Modbus
address
（HEX）
Function Range Type Latched Attribute
D27431 EB27
The allowed error between the
given and feedback pulse
number
-- UINT No Read only
D27435 EB2B
Current torque (Rated torque
permillage)
-- INT No Read only
D27436 EB2C
Current speed (Unit: 0.1 r/min）
--
DINT
No Read only
D27437 EB2D -- No Read only
D27438 EB2E
Present current (Rated current
permillage)
-- INT No Read only
D27439 EB2F
Custom parameter value
--
DINT
No Read only
D27440 EB30 -- No Read only
D27441 EB31
The phase of the terminal
actuator
0~ modulo REAL
No Read only
D27442 EB32
D27443 EB33
The position of the terminal
actuator
-2147483648
~
2147483647
DINT
No Read only
D27444 EB34
Note: The axis parameter values such as Position, Velocity, Torque, Current and User-defined
parameter can be read via special D only when they are selected. For the method of selecting
the relevant parameter, see section 2.3.1.
