Appendix C
C-10 DVP-MC operating manual
Special
D
Modbus
address
（HEX）
Function Range Type Latched Attribute
D25630 E41E
Axis current state (See
section 4.2）
UINT No Read only
D25637 E425 Pulse number needed
when servo motor rotates
for one circle.
--
DINT
No Read only
D25638 E426 -- No Read only
D25639 E427
The allowed error between
the given and feedback
pulse number
-- UINT No Read only
D25643 E42B
Current torque (Rated
torque permillage)
-- INT No Read only
D25644 E42C
Current speed (Unit: 0.1
r/min）
--
DINT
No Read only
D25645 E42D -- No Read only
D25646 E42E
Present current (Rated
current permillage)
-- INT No Read only
D25647 E42F
Custom parameter value
--
DINT
No Read only
D25648 E430 -- No Read only
D25649 E431
The phase of the terminal
actuator
0~ modulo REAL
No Read only
D25650 E432
D25651 E433
The position of the terminal
actuator
-2147483648
~
2147483647
DINT
No Read only
D25652 E434
Note: The axis parameter values such as Position, Velocity, Torque, Current and User-defined
parameter can be read via special D only when they are selected. For the method of selecting
the relevant parameter, see section 2.3.1.
