3. System Installation
3-2 DVP-MC operating manual
Electrical specification for the output point
Item Content
Input channel
number
4 transistors for output (Source)
Channel type
High-speed digital output type for the 4 channels
Output terminals Terminal: Q0, Q1, Q2, Q3
Power voltage for
output point
24 VDC（-15% ~ +20%）
#1
Output delay
2µS
（
Off -> On
）
, 3µS
（
On -> Off
）
Max switch
frequency
1KHZ
Max loading
Resistance: 0.5A/1point （2A/ZP）
Inductance: 15W（30VDC）
Bulb: 2.5W（30VDC）
Max cable length
The Shielded cable: 500m
The cable without a shield wire: 300m
#1: UP and ZP must connect the auxiliary power 24VDC (-15%~20%).
