Appendix C
C-30 DVP-MC operating manual
Special
D
Modbus
address
（HEX）
Function Range Type Latched Attribute
D28197 EE25
Pulse number needed when
servo motor rotates for one
circle.
--
DINT
No Read only
D28198 EE26 -- No Read only
D28199 EE27
The allowed error between the
given and feedback pulse
number
-- UINT No Read only
D28203 EE2B
Current torque (Rated torque
permillage)
-- INT No Read only
D28204 EE2C
Current speed (Unit: 0.1 r/min）
--
DINT
No Read only
D28205 EE2D -- No Read only
D28206 EE2E
Present current (Rated current
permillage)
-- INT No Read only
D28207 EE2F
Custom parameter value
--
DINT
No Read only
D28208 EE30 -- No Read only
D28209 EE31
The phase of the terminal
actuator
0~ modulo REAL
No Read only
D28210 EE32
D28211 EE33
The position of the terminal
actuator
-2147483648
~
2147483647
DINT
No Read only
D28212 EE34
Note: The axis parameter values such as Position, Velocity, Torque, Current and User-defined
parameter can be read via special D only when they are selected. For the method of selecting
the relevant parameter, see section 2.3.1.
