Appendix C
C-6 DVP-MC operating manual
Special
D
Modbus
address
（HEX）
Function Range Type Latched Attribute
D25125 E225 Pulse number needed when
servo motor rotates for one
circle.
--
DINT
No Read only
D25126 E226 -- No Read only
D25127 E227
The allowed error between
the given and feedback pulse
number
-- UINT No Read only
D25131 E22B
Current torque (Rated torque
permillage)
-- INT No Read only
D25132 E22C
Current speed (Unit: 0.1
r/min）
--
DINT
No Read only
D25133 E22D -- No Read only
D25134 E22E
Present current (Rated
current permillage)
-- INT No Read only
D25135 E22F
Custom parameter value
--
DINT
No Read only
D25136 E230 -- No Read only
D25137 E231
The phase of the terminal
actuator
0~ modulo REAL
No Read only
D25138 E232
D25139 E233
The position of the terminal
actuator
-2147483648
~
2147483647
DINT
No Read only
D25140 E234
Note: The axis parameter values such as Position, Velocity, Torque, Current and User-defined
parameter can be read via special D only when they are selected. For the method of selecting
the relevant parameter, see section 2.3.1.
