Appendix C
DVP-MC operating manual C-19
Special registers related with axis 10
Special
D
Modbus
address
（HEX）
Function Range Type Latched Attribute
D26880 E900 Type（0: rotary 1: linear） 0-1 UINT No Read only
D26881 E901
Modulo -- DINT
No Read only
D26882 E902 No Read only
D26883 E903
Acceleration and deceleration
type（0:T 1: S 2:JERK）
0-2 UINT No Read only
D26884 E904 Numerator of electronic gear 0 - 65535 UINT No Read only
D26885 E905 Denominator of electronic gear 0 - 65535 UINT No Read only
D26886 E906
Software limit（0:disable,
1:enable）
0-1 UINT No Read only
D26887 E907
The positive position limit
--
DINT
No Read only
D26888 E908 -- No Read only
D26889 E909
The negative position limit
--
DINT
No Read only
D26890 E90A -- No Read only
D26891 E90B
Homing mode; please refer to
appendix D
1-35 UINT No Read only
D26892 E90C
Homing speed
(Unit: r/min)
--
UDINT
No Read only
D26893 E90D -- No Read only
D26894 E90E
Maximum speed
（Unit: unit/ second）
--
UDINT
No Read only
D26895 E90F -- No Read only
D26896 E910
Maximum acceleration
（Unit: unit/ second
2
）
--
UDINT
No Read only
D26897 E911 -- No Read only
D26898 E912
Maximum deceleration
（Unit: unit/ second
2
）
--
DINT
No Read only
D26899 E913 -- No Read only
D26900 E914
Given position（Unit: pulse）
--
DINT
No Read only
D26901 E915 -- No Read only
D26902 E916
Given speed
(Unit: pulse/second）
--
DINT
No Read only
D26903 E917 -- No Read only
D26904 E918
Given acceleration
（Pulse/second
2
）
--
DINT
No Read only
D26905 E919 -- No Read only
D26906 E91A
Current position (Unit: pulse)
--
DINT
No Read only
D26907 E91B -- No Read only
D26908 E91C
Current position error (Unit:
pulse)
--
DINT
No Read only
D26909 E91D -- No Read only
D26910 E91E
Axis current state (See section
4.2）
UINT No Read only
D26917 E925 Pulse number needed when
servo motor rotates for one
circle.
--
DINT
No Read only
D26918 E926 -- No Read only
