Appendix C
C-28 DVP-MC operating manual
Special
D
Modbus
address
（HEX）
Function Range Type Latched Attribute
D27941 ED25 Pulse number needed when
servo motor rotates for one
circle.
--
DINT
No Read only
D27942 ED26 -- No Read only
D27943 ED27
The allowed error between
the given and feedback
pulse number
-- UINT No Read only
D27947 ED2B
Current torque (Rated
torque permillage)
-- INT No Read only
D27948 ED2C
Current speed (Unit: 0.1
r/min）
--
DINT
No Read only
D27949 ED2D -- No Read only
D27950 ED2E
Present current (Rated
current permillage)
-- INT No Read only
D27951 ED2F
Custom parameter value
--
DINT
No Read only
D27952 ED30 -- No Read only
D27953 ED31
The phase of the terminal
actuator
0~ modulo REAL
No Read only
D27954 ED32
D27955 ED33
The position of the terminal
actuator
-2147483648
~
2147483647
DINT
No Read only
D27956 ED34
Note: The axis parameter values such as Position, Velocity, Torque, Current and User-defined
parameter can be read via special D only when they are selected. For the method of selecting
the relevant parameter, see section 2.3.1.
