Appendix C
DVP-MC operating manual C-21
Special registers related with axis 11
Special
D
Modbus
address
（HEX）
Function Range Type Latched Attribute
D27136 EA00 Type（0: rotary 1: linear） 0-1 UINT No Read only
D27137 EA01
Modulo -- DINT
No Read only
D27138 EA02 No Read only
D27139 EA03
Acceleration and deceleration
type（0:T 1: S 2:JERK）
0-2 UINT No Read only
D27140 EA04 Numerator of electronic gear 0 - 65535 UINT No Read only
D27141 EA05 Denominator of electronic gear 0 - 65535 UINT No Read only
D27142 EA06
Software limit（0:disable,
1:enable）
0-1 UINT No Read only
D27143 EA07
The positive position limit
--
DINT
No Read only
D27144 EA08 -- No Read only
D27145 EA09
The negative position limit
--
DINT
No Read only
D27146 EA0A -- No Read only
D27147 EA0B
Homing mode; please refer to
appendix D
1-35 UINT No Read only
D27148 EA0C
Homing speed
(Unit: r/min)
--
UDINT
No Read only
D27149 EA0D -- No Read only
D27150 EA0E
Maximum speed
（Unit: unit/ second）
--
UDINT
No Read only
D27151 EA0F -- No Read only
D27152 EA10
Maximum acceleration
（Unit: unit/ second
2
）
--
UDINT
No Read only
D27153 EA11 -- No Read only
D27154 EA12
Maximum deceleration
（Unit: unit/ second
2
）
--
DINT
No Read only
D27155 EA13 -- No Read only
D27156 EA14
Given position（Unit: pulse）
--
DINT
No Read only
D27157 EA15 -- No Read only
D27158 EA16
Given speed
(Unit: pulse/second）
--
DINT
No Read only
D27159 EA17 -- No Read only
D27160 EA18
Given acceleration
（Pulse/second
2
）
--
DINT
No Read only
D27161 EA19 -- No Read only
D27162 EA1A
Current position (Unit: pulse)
--
DINT
No Read only
D27163 EA1B -- No Read only
D27164 EA1C
Current position error (Unit:
pulse)
--
DINT
No Read only
D27165 EA1D -- No Read only
D27166 EA1E
Axis current state (See section
4.2）
UINT No Read only
D27173 EA25 Pulse number needed when
servo motor rotates for one
circle.
--
DINT
No Read only
D27174 EA26 -- No Read only
