Appendix C
C-8 DVP-MC operating manual
Special
D
Modbus
address
（HEX）
Function Range Type Latched Attribute
D25383 E327
The allowed error between the
given and feedback pulse
number
-- UINT No Read only
D25387 E32B
Current torque (Rated torque
permillage)
-- INT No Read only
D25388 E32C
Current speed (Unit: 0.1 r/min）
--
DINT
No Read only
D25389 E32D -- No Read only
D25390 E32E
Present current (Rated current
permillage)
-- INT No Read only
D25391 E32F
Custom parameter value
--
DINT
No Read only
D25392 E330 -- No Read only
D25393 E331
The phase of the terminal
actuator
0~ modulo REAL
No Read only
D25394 E332
D25395 E333
The position of the terminal
actuator
-2147483648
~
2147483647
DINT
No Read only
D25396 E334
Note: The axis parameter values such as Position, Velocity, Torque, Current and User-defined
parameter can be read via special D only when they are selected. For the method of selecting
the relevant parameter, see section 2.3.1.
