• Do not expose the charger to humidity or water. Ingress of water into the
charger increases risk of electric shock. Use the charger only in dry rooms.
• Disconnect the charger from power supply before starting any maintenance
or cleaning.
• Do not use the charger when placed on ammable surface (e.g. paper,
textiles) or in proximity of ammable substance. Greater charger
temperature when charging increases risk of re.
• Check condition of the charger, cable and plug before each use. Do
not use the charger if any damage is found. Do not try to disassemble
the charger. All repairs should be made at an authorized service workshop.
Improper charger assembly may cause electric shock or re.
• Children or persons who are physically, emotionally or mentally disabled
and other persons, whose experience or knowledge is insucient to use
the charger while following all safety rules should not use the charger
without supervision of person responsible for their safety. Otherwise there
is a risk of improper use and injuries in consequence.
• When the charger is not in use, it should be disconnected from the
mains network.
• Observe all charging instructions. Do not charge the battery in
temperature outside of range dened in the rating data table from the
instruction manual. Incorrect charging or charging in temperature outside of
dened range may damage the battery and increase the risk of re.
CHARGER REPAIRS
• Do not repair damaged charger. The charger can be repaired only by the
manufacturer or in an authorised workshop.
• When disposing of the worn out charger, take it to a service point
where you can utilize such wastes.
CAUTION! This device is designed to operate indoors.
The design is assumed to be safe, protection measures and additional
safety systems are used, nevertheless there is always a small risk of
injuries at work.
Li-Ion batteries may leak, set on re or explode when heated to high
temperature or short-circuited. Do not store the batteries in a car in
hot and sunny days. Do not open the battery. Li-Ion batteries contain
electronic protection devices that, if damaged, may cause re or
explosion of the battery.
SAFETY RULES FOR LASER DEVICE
Laser device used in the saw design is the class 2 with maximum power
below 1 mW and wavelength λ = 650 nm. Such device is not dangerous
to eyes, however do not look directly at the source of the light (temporary
blindness hazard).
WARNING. Do not look directly at the source of the laser beam. It may
cause hazards. Follow the below safety rules.
• Use the laser device in accordance with the manufacturer’s instructions.
• Do not, either intentionally or unintentionally, point the laser beam at
people, animals or any object other than processed material.
• Do not bring to accidental pointing the laser beam at bystanders’ or
animals’ eyes for a period longer than 0.25 second, for instance by pointing
the laser beam at mirrors.
• Always ensure the laser beam is directed at material which does not have
any reective surfaces.
• Reective steel sheet (and other materials with reective surface) does
not allow for laser use, because it might cause hazardous light reection
directed at operator, bystanders or animals.
• Do not replace the laser unit with device of other type. All repairs must be
carried out by the manufacturer or authorized person.
LASER LIGHT, LASER RADIATION
DO NOT LOOK AT THE LASER BEAM
LASER DEVICE CLASS 2
Wavelength: 650 nm; Output: < 1 mW
EN 60825-1:2014
Caution: Laser radiation.
CAUTION: Adjustments other than described in this manual put in
danger of exposition to laser radiation!
Explanation of used symbols
1
2
3
Max.
50°C
4
5
6 7
109
8
11 12
13 14 15
1. Read instruction manual, observe warnings and safety conditions therein.
2. Use protective goggles and hearing protectors.
3. Work with protective mask on.
4. Keep the tool away from children.
5. Protect against rain.
6. Use indoors, protect from water and moisture.
7. Be careful, sharp edges!
8. Use protective gloves
9. Recycling.
10. Protection class 2.
11. Segregated waste collection.
12. Do not throw cells into re.
13. Hazardous to water environment.
14. Do not allow to heat above 50°C
15. Caution: Laser radiation.
CONSTRUCTION AND USE
Circular saw is a battery-powered tool. Drive consists of a DC commutator
motor with permanent magnets and gear. Power tools of this type are
widely used for cutting wood and wood-based materials. Do not use the
saw for cutting rewood. Attempts to use the saw for purposes other than
specied will be considered an improper use. Use the circular saw only with
appropriate cutting blades with teeth with sintered carbide tips. Circular saw
is designed for light duty works in service workshops and any individual,
amateur activities (tinkering).
Use the tool in accordance with the manufacturer’s instructions
only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing
pages of this manual.
1. Dust extraction outlet
2. Upper guard
3. Switch lock button
4. Switch
5. Lower guard lever
6. Front handle
7. Laser
8. Cutting blade
9. Flange washer
10. Fixing bolt for cutting blade
11. Lower guard
12. Spindle lock button
13. Main handle
14. Battery installation socket
15. Cutting depth locking lever
16. Base
17. Base position locking lever
18. Cutting line indicator for 45°
19. Cutting line indicator for 0°
20. Edge guide locking screw
21. Edge guide
22. Cutting depth guide
