DFL-1000 User Manual
10
0
Enable perfect forward secrecy
(PFS)
Select Select Select Select
DH Group
5 5 5 5
Keylife
300 seconds 300 seconds 300 seconds 300 seconds
Autokey Keep Alive
Enable Enable Enable Enable
Concentrator
Not selected Not selected Not selected Not selected
Configuring the VPN concentrator
For the Main Office (the hub), create the VPN concentrator and add the appropriate members to it. Add
all the tunnels that are part of the same hub and spoke configuration to the same VPN concentrator.
If you add a spoke to the configuration after you create the VPN concentrator, you can add the new VPN
tunnel to the VPN concentrator by selecting the concentrator name while you are configuring the tunnel.
Example VPN concentrator configuration
shows the information required to configure the VPN
concentrator.
Example VPN concentrator configuration
Field name VPN concentrator information
Concentrator Name
Main_Office_Concentrator
Members
Branch1_VPN
Branch2_VPN
To add a VPN concentrator:
• Go to VPN > IPSec > Concentrator.
• Select New to add a VPN concentrator.
• Enter the name of the new VPN concentrator in the Concentrator Name field.
• Select Branch1_VPN in the Available Tunnels list and select the right arrow.
The tunnel moves to the Members list.
•
Select Branch2_VPN in the Available Tunnels list and select the right arrow.
The tunnel moves to the Members list.
• Select OK to add the VPN concentrator.
Adding source and destination addresses
Add source and destination addresses for the Main Office, Branch 1, and Branch 2.
Use the procedure Adding source and destination addresses for a remote client VPN
.
Use the information in Example IPSec source and destination address information
to add the source and
destination addresses. You need to add the addresses for each location individually.
Example IPSec source and destination address information
Field name Main Office information Branch 1 information Branch 2 information
Source Address
Address Name
Main_Office Branch1 Branch2
IP address
192.168.1.0 192.168.2.0 192.168.3.0
Netmask
255.255.255.0 255.255.255.0 255.255.255.0
Destination Address
Address Name
Branch1 Branch2 Main_Office Main_Office
IP address
192.168.2.0 192.168.3.0 192.168.1.0 192.168.1.0
