D-Link DFL-1000 [27/168] Transparent mode installation
![D-Link DFL-1000 [27/168] Transparent mode installation](/views2/1045575/page27/bg1b.png)
DFL-1000 User Manual
2
7
Transparent mode installation
This chapter describes how to install your DFL-1000 NPG in Transparent mode. If you want to install the
DFL-1000 NPG in NAT/Route mode, see NAT/Route mode installation
.
This chapter includes:
•
Preparing to configure Transparent mode
•
Using the setup wizard
•
Using the command line interface
• Setting the date and time
• Connecting to your networks
Preparing to configure Transparent mode
Use Transparent mode settings to gather the information that you need to customize Transparent mode
settings.
Transparent mode settings
Administrator Password:
IP:
_____._____._____._____
Netmask:
_____._____._____._____
Default Gateway:
_____._____._____._____
Management
IP
The management IP address and netmask must be valid for the network from which you will manage
the DFL-1000 NPG. Add a default gateway if the DFL-1000 NPG must connect to a router to reach
the management computer.
Primary DNS Server:
_____._____._____._____
DNS Settings
Secondary DNS Server:
_____._____._____._____
Using the setup wizard
From the web-based manager, you can use the setup wizard to create the initial configuration of your
DFL-1000 NPG. To connect to the web-based manager, see Connecting to the web-based manager
.
Changing to Transparent mode
The first time that you connect to the DFL-1000 NPG, it is configured to run in NAT/Route mode. To
switch to Transparent mode using the web-based manager:
• Go to System > Status .
• Select Change to Transparent Mode.
• Select Transparent in the Operation Mode list.
• Select OK.
The DFL-1000 NPG changes to Transparent mode.
To reconnect to the web-based manager, change the IP address of your management computer to
10.10.10.2. Connect to the DFL-1000 NPG internal or DMZ interface and browse to https:// followed by
