DFL-1000 User Manual

5

9

If you are using accept policies to restrict access, you must remove all general access policies, such as

the default policy, that could be matched by a connection that you do not want. For more information, see

Policy matching in detail

and Configuring policy lists.

Requiring authentication to connect to the Internet

To require authentication, you must add users and user groups to the firewall configuration (see Users

and authentication). You can then add policies to require users to enter a user name and password to

access services through the firewall.

You can require authentication:

• for policies between any two interfaces,

• to connect to selected addresses,

• according to a schedule.

You can select authentication for any service. Users can authenticate with the firewall using HTTP, Telnet,

or FTP. For users to be able to authenticate, you must add an HTTP, Telnet, or FTP policy that is

configured for authentication. When users attempt to connect through the firewall using this policy, they

are prompted to enter a firewall user name and password.

If you want users to authenticate to use other services (for example, POP3 or IMAP), you can create a

service group that includes the services for which you want to require authentication as well as HTTP,

Telnet, and FTP. Users can then authenticate with the policy using HTTP, Telnet, or FTP before using the

other service.

In most cases, you should make sure that users can use DNS through the firewall without authentication.

If DNS is not available, users cannot connect to a web, FTP, or Telnet server using a domain name.

The following example procedure describes how to configure the firewall to require users on the internal

network to authenticate to access POP3 servers on the Internet. In this example, the DFL-1000 NPG is

running in NAT/Route mode, but the configuration would be the same for a DFL-1000 NPG running in

Transparent mode.

To require authentication:

• Add at least one user group to the firewall.

See Users and authentication

.

•

Go to Firewall > Service > Group .

•

Select New to add a Service Group.

•

Enter a Group Name for the New Service Group and add the POP3, HTTP, FTP, and Telnet services

to the service group Members list.

•

Go to Firewall > Policy > Int->Ext .

•

Select New to add a new policy.

You can also select Insert Policy before

on a policy in the list to add the new policy above a

specific policy.

•

Configure the policy to match the type of connection for which to require authentication:

Set Service to the service group that you added in step Enter a Group Name for the New Service

Group and add the POP3, HTTP, FTP, and Telnet services to the service group Members list..

Set Action to ACCEPT.

•

Select Authentication and select the user group that you added in step Add at least one user group to

the firewall..

•

Select OK to save the policy.

You must add the policy requiring authentication above the default policy and above any matching accept

policies in the policy list. For more information, see Policy matching in detail

and Configuring policy lists.
