DFL-1000 User Manual
114
Enabling the banned word list
• Go to Web Filter > Content Block .
• Select Enable Banned Word to turn on content blocking.
The DFL-1000 NPG is now configured to block web pages containing words and phrases added to
the banned word list.
Changing the content block message
To customize the message that users receive when the DFL-1000 NPG blocks web content:
•
Go to Web Filter > Content Block .
•
Select Edit Prompt
to edit the content block message.
•
Edit the text of the message. You can include HTML code in the message.
•
Select OK to save your changes.
The DFL-1000 NPG displays the message when content is blocked.
Adding words and phrases to the banned word list
•
Go to Web Filter > Content Block .
•
Select New to add a word or phrase to the banned word list.
•
Choose a language or character set for the banned word or phrase.
You can choose Western, Chinese Simplified, Chinese Traditional, Japanese, or Korean.
Your computer and web browser must be configured to enter characters in the character set that you
choose.
•
Type a banned word or phrase.
If you type a single word (for example, banned ), the DFL-1000 NPG blocks all web pages that
contain that word.
If you type a phrase (for example, banned phrase ), the DFL-1000 NPG blocks web pages that
contain both words. When this phrase appears on the banned word list, the DFL-1000 NPG inserts
plus signs (+) in place of spaces (for example, banned+phrase ).
If you type a phrase in quotes (for example,
"banned word"
), the DFL-1000 NPG blocks all web
pages in which the words are found together as a phrase.
Content filtering is not case-sensitive. You cannot include special characters in banned words.
•
Select OK.
The word or phrase is added to the banned word list.
• In the Modify column, check the box beside the new entry in the banned word list so that the DFL-
1000 NPG blocks web pages containing this word or phrase.
You can enter multiple banned words or phrases and then select Check All
to activate all entries
in the banned word list.
