DFL-1000 User Manual
11
8
Temporarily disabling the URL block list
• Go to Web Filter > URL Block .
• Uncheck Enable URL Block to disable URL blocking.
Temporarily disabling individual URL blocking
• Go to Web Filter > URL Block .
•
To page through the URL block list to find a URL, select Page Down
or Page Up .
•
To disable a URL, select Edit
.in the Modify column.
• Uncheck Enable.
• Select OK to save your changes.
•
You can also select Uncheck All
to uncheck all items in the URL block list.
All unchecked items in the URL block list are not blocked by the DFL-1000 NPG.
Clearing the URL block list
•
Go to Web Filter > URL Block .
• Select Clear URL Block List
to remove all URLs from the URL block list.
Downloading the URL block list
If you make changes to the URL block list using the web-based manager, you can download the list to a
text file using the following procedure:
•
Go to Web Filter > URL Block .
• Select Download URL Block list
.
The DFL-1000 NPG downloads the list to a text file on the management computer.
Uploading a URL block list
You can create a URL block list in a text editor and then upload the text file to the DFL-1000 NPG. Add
one URL to each line of the text file. You can follow the URL with a space and then a 1 to enable or a
zero (0) to disable the URL. If you do not add this information to the text file, the DFL-1000 NPG
automatically enables all URLs in the block list when you upload the text file.
Sample URL block list text file
www.badsite.com/index 1
www.badsite.com/products 1
182.33.44.34/index 1
You can either create the URL block list yourself, or add a URL list created by a third-party URL block or
blacklist service. For example, you can download the squidGuard blacklists available at
http://www.squidguard.org/blacklist/ as a starting point for creating your own URL block list. Three times a
week, the squidGuard robot searches the web for new URLs to add to the blacklists. You can upload the
squidGuard blacklists to the DFL-1000 NPG as a text file, with only minimal editing to remove comments
at the top of each list and to combine the lists that you want into a single file.
All changes made to the URL block list using the web-based manager are lost when you upload a new list.
However, you can download your current URL list, add more URLs to it using a text editor, and then upload the
edited list to the DFL-1000 NPG.
In a text editor, create the list of URLs to block.
•
Using the web-based manager, go to Web Filter > URL Block .
