DFL-1000 User Manual
1
8
Mounting
The DFL-1000 NPG can be installed on any stable surface. Make sure that the appliance has at least 1.5
in. (3.75 cm) of clearance on each side to allow for adequate air flow and cooling.
The DFL-1000 NPG can also be mounted on a standard 19-inch rack. It requires 1 U of vertical space in
the rack.
Dimensions
16.8 x 10 x 1.75 in. (42.7 x 25.4 x 4.5 cm)
Weight
7.3 lb. (3.3 kg)
Power requirements
Power dissipation: 50 W (max)
AC input voltage: 100 to 240 VAC
AC input current: 1.6 A
Frequency: 50 to 60 H
Environmental specifications
Operating temperature: 32 to 104°F (0 to 40°C)
Storage temperature: -13 to 158°F (-25 to 70°C)
Humidity: 5 to 95% non-condensing
Powering on
To power on the DFL-1000 NPG:
Make sure that the power switch on the back of the DFL-1000 NPG is turned off.
Connect the power cable to the power connection at the back of the DFL-1000 NPG.
Connect the power cable to a power outlet.
Turn on the power switch.
The DFL-1000 NPG starts up. The Power and Status lights light. The Status light flashes while the
DFL-1000 NPG is starting up and remains lit when the system is up and running.
Front and back view of the DFL-1000 NPG
DFL-1000 LED indicators
LED State Description
Green The DFL-1000 NPG is powered on.
Power
Off The DFL-1000 NPG is powered off.
Flashing green The DFL-1000 NPG is starting up.
Status
Green The DFL-1000 NPG is running normally.
