DFL-1000 User Manual
8
6
You can use any characters for the authentication key. The authentication key must be the same on both
gateways.
For more information about remote gateway settings, see Adding a remote gateway.
To configure the remote gateways for the Main Office and Branch Office:
• Go to VPN > IPSEC > Remote Gateway .
• Select New to add a remote gateway.
• On the Main Office DFL-1000 NPG configure the remote gateway using the Main Office information in
Example remote gateway configuration
.
• On the Branch Office DFL-1000 NPG configure the remote gateway using the Branch Office
information in Example remote gateway configuration
.
• Select OK to save the remote gateway.
Configuring the AutoIKE key tunnel for a remote network
Use the following procedure to configure the AutoIKE key tunnel for the example VPN in Example VPN
between two internal networks.
Example AutoIKE key tunnel configuration
shows the information required to configure the tunnel.
Example AutoIKE key tunnel configuration
Field name Main Office information Branch Office information
Tunnel Name
Branch_Office_VPN Main_Office_VPN
Remote Gateway
Branch_Office_gw Main_Office_gw
P2 Proposal
1- Encryption
3DES 3DES
Authentication
SHA1 SHA1
Enable replay detection
Select Select
Enable perfect forward secrecy (PFS)
Select Select
DH Group
5 5
Keylife
300 seconds 300 seconds
Autokey Keep Alive
Enable Enable
Concentrator
Not selected Not selected
For more information about AutoIKE key tunnel settings, see Adding an AutoIKE key VPN tunnel.
To configure the AutoIKE key tunnel for the Main Office and Branch Office VPN gateways:
•
Go to VPN > IPSEC > AutoIKE Key .
•
Select New to add an AutoIKE key tunnel.
• On the Main Office DFL-1000, configure the AutoIKE key tunnel using the Main Office information in
Example AutoIKE key tunnel configuration
.
•
On the Branch Office DFL-1000, configure the AutoIKE key tunnel using the Branch Office
information in Example AutoIKE key tunnel configuration
.
•
Select OK to save the AutoIKE key tunnel.
