Configuring remote IPSec VPN gateways for dialup VPN
•
Configuring remote IPSec VPN clients for dialup VPN
Adding a dialup remote gateway
Use the information in Example dialup remote gateway to configure the remote gateway.
Example dialup remote gateway
Field name Remote gateway information
Gateway Name
Dialup_gw
Remote Gateway
Dialup User
User Group
None
Mode
Main (ID Protection)
P1 Proposal
1 Encryption
3DES
Authentication
SHA1
DH Group
5
Keylife
28800 seconds
Authentication
(Pre-shared Key)
ddcHH01887d
Local ID
Blank
Nat-traversal
Not Selected
Keepalive Frequency
Blank
To configure the example remote gateway:
• Go to VPN > IPSEC > Remote Gateway .
• Select New to add a remote gateway.
• Configure the remote gateway using the information in Example dialup remote gateway
.
For information about remote gateway settings, see Adding a remote gateway.
•
Select OK to save the dialup VPN remote gateway.
Adding AutoIKE key tunnels for dialup VPN
If you are configuring dialup VPN for a network-to-network VPN, use the procedure in Configuring the
AutoIKE key tunnel for a remote network. Use the information in Example AutoIKE key tunnel
configuration, but set the AutoIKE key tunnel remote gateway to the Dialup_gw gateway that you created.
If you are configuring dialup VPN for a remote client, use the procedure in Configuring the AutoIKE key
tunnel for a remote client. Use the information in Example AutoIKE key tunnel configuration, but set the
AutoIKE key tunnel remote gateway to the Dialup_gw gateway that you created.
Adding source and destination addresses for dialup VPN
If you are configuring dialup VPN for a network-to-network VPN, use the procedures in Adding source
and destination addresses for a network-to-network VPN. Use the information in IPSec VPN source and
destination addresses.
If you are configuring dialup VPN for a remote client, use the procedures in Adding source and
destination addresses for a remote client VPN. Use the information in Example source and destination
addresses for a client with a static IP address.
