IPSec VPNs
Using IPSec Virtual Private Networking (VPN), you can join together two or more widely separated private
networks across a wide area network (WAN) such as the Internet. For example, a company that has two
offices in different cities, each with its own private network, can use VPN to create a secure tunnel
between the offices. Remote or travelling workers can use a VPN client to connect to their office private
network.
The DFL-1000 NPG is an excellent choice for connecting a satellite office to a main office VPN. The main
office would usually be protected by a high-capacity product such as the DFL-1000-400 NPG or DFL-
1000-500 NPG. The small office requires the same security and functionality, but the smaller user base
makes the DFL-1000 NPG the product of choice for protecting smaller networks.
The secure IPSec VPN tunnel makes it appear to all VPN users that they are on physically connected
networks. The VPN protects data passing through the tunnel by encrypting it to guarantee confidentiality.
In addition, authentication guarantees that the data originated from the claimed sender and was not
damaged or altered in transit.
IPSec is an Internet security standard for VPN and is supported by most VPN products. DFL-1000 IPSec
VPNs support three VPN configurations:
•
Auto Internet Key Exchange (IKE) key VPN
•
Manual Key Exchange VPN
•
Dialup VPN
Both AutoIKE key and manual key configurations are used to connect remote clients or VPN gateways
that have static IP addresses to a DFL-1000 VPN gateway. Dialup VPN uses an AutoIKE key
configuration that allows clients or remote gateways with dynamic IP addresses to connect to the DFL-
1000 VPN gateway.
IPSec VPN is not supported in Transparent mode.
This chapter describes:
• Interoperability with IPSec VPN products
• Configuring AutoIKE key IPSec VPN
•
Configuring manual key IPSec VPN
•
Configuring dialup VPN
•
Configuring a VPN Concentrator for hub and spoke VPN
•
Configuring IPSec redundancy
•
Adding a remote gateway
•
Adding an AutoIKE key VPN tunnel
•
Adding a manual key VPN tunnel
•
Adding a VPN concentrator
•
Adding an encrypt policy
•
Viewing VPN tunnel status
• Viewing dialup VPN connection status
• Testing a VPN
