Both ends of a gateway must have the same NAT traversal setting. Each end can have different keepalive
frequencies.
Adding an AutoIKE key VPN tunnel
Add an AutoIKE key tunnel to specify the parameters used to create and maintain a VPN tunnel that has
been started by a remote gateway configuration.
To add an AutoIKE key VPN tunnel:
• Go to VPN > IPSEC > AutoIKE Key .
• Select New to add a new AutoIKE key VPN tunnel.
• Configure the AutoIKE key VPN tunnel.
Tunnel Name
Enter a name for the tunnel. The name can contain numbers (0-9), uppercase and lowercase
letters (A-Z, a-z), and the special characters - and _. Other special characters and spaces are
not allowed.
Remote Gateway
Select a STATIC or a DIALUP remote gateway to associate with the VPN tunnel.
Select a static remote gateway if you are configuring IPSec redundancy. See Configuring
IPSec redundancy.
If you select a static gateway, you can select up to three remote gateways. To decrease the
number of remote gateways, select the minus sign. To increase the number of remote
gateways, select the plus sign.
P2 Proposal
Select up to three encryption and authentication algorithm combinations to propose for phase
2. Two are selected by default. To decrease the number of combinations selected, select the
minus sign. To increase the number of combinations selected, select the plus sign. See About
the P2 proposal.
Enable replay
detection
Select Enable replay detection to prevent IPSec replay attacks during phase 2. See About
replay detection.
Enable perfect
forward secrecy
(PFS)
Select Enable perfect forward secrecy (PFS) to improve the security of phase 2 keys. See
About perfect forward secrecy (PFS)
.
DH Group
Select the Diffie-Hellman group to propose for phase 2 of the IPSec VPN connection. You can
select one DH group. Select 1, 2, or 5. See About DH groups
.
Keylife
Specify the keylife for phase 2. The keylife causes the phase 2 key to expire after a specified
amount of time, after a specified number of kbytes of data have been processed by the VPN
tunnel, or both. If you select both, the key does not expire until both the time has passed and
the number of kbytes have been processed.
When the key expires, a new key is generated without interrupting service. P2 proposal keylife
can be from 120 to 172800 seconds or from 5120 to 99999 kbytes.
Autokey Keep
Alive
Enable Autokey Keep Alive to keep the VPN tunnel running even if no data is being processed.
Concentrator
Select a concentrator if you want the tunnel to be part of a hub and spoke VPN configuration. If
you use the procedure, Adding a VPN concentrator
to add the tunnel to a concentrator, the
next time you open the tunnel, the Concentrator field displays the name of the concentrator to
which you have added the tunnel.
•
Select OK to save the AutoIKE key VPN tunnel.
