DFL-1000 User Manual
15
3
•
Go to System > Config > Admin .
•
To change an administrator account password, select Change Password
.
•
Type the Old Password.
•
Type a New Password and Confirm the new password.
The password must be at least 6 characters long and can contain numbers (0-9), uppercase and
lowercase letters (A-Z, a-z), and the special characters - and _. Other special characters and spaces
are not allowed.
•
Select OK.
•
To edit the settings of an administrator account, select Edit
.
•
Optionally type a Trusted Host IP address and netmask for the location from which the administrator
can log into the web-based manager.
If you want the administrator to be able to access the DFL-1000 NPG from any address, set the
trusted host to 0.0.0.0 and the wildcard mask to 255.255.255.255.
To limit the administrator to only be able to access the DFL-1000 NPG from a specific network, set
the trusted host to the address of the network and set the wildcard mask to the netmask for the
network. For example, to limit an administrator to accessing the DFL-1000 NPG from your internal
network, set the trusted host to the address of your internal network (for example, 192.168.1.0) and
set the wildcard mask to 255.255.255.0.
• Change the administrator's permission level as required.
• Select OK.
• To delete an administrator account, choose the account to delete and select Delete
.
Configuring SNMP
Configure SNMP for the DFL-1000 NPG so that the SNMP agent running on the DFL-1000 NPG can
report system information and send traps. The DFL-1000 agent supports SNMP v1 and v2c. System
information can be monitored by any SNMP manager configured to get system information from your
DFL-1000 NPG. Your SNMP manager can use GET (GET-NEXT) SNMP operations to communicate with
the DFL-1000 agent.
Configuring the DFL-1000 NPG for SNMP connections
Before a remote SNMP manager can connect to the DFL-1000 SNMP agent, you must configure one or
more interfaces to accept SNMP connections. For information about how to do this, see Configuring the
internal interface and related interface configuration sections.
Configuring SNMP
•
Go to System > Config > SNMP .
•
Select Enable SNMP.
•
Configure SNMP settings:
System Name
Type a name for this DFL-1000 NPG. The system name can be up to 31 characters long and can
contain numbers (0-9), uppercase and lowercase letters (A-Z, a-z), and the special characters -
and _. Spaces and the \ < > [ ] ` $ % & characters are not allowed.
System
Location
Describe the physical location of the DFL-1000 NPG. The system location description can be up to
31 characters long and can contain spaces, numbers (0-9), uppercase and lowercase letters (A-Z,
a-z), and the special characters - and _. The \ < > [ ] ` $ % & characters are not allowed.
Contact
Information
Add the contact information for the person responsible for this DFL-1000 NPG. The contact
information can be up to 31 characters long and can contain spaces, numbers (0-9), uppercase
and lowercase letters (A-Z, a-z), and the special characters - and _. The \ < > [ ] ` $ % &
characters are not allowed.
