DFL-1000 User Manual
2
3
User name:
PPPoE:
Password:
If your ISP supplies you with an IP address using PPPoE, record your PPPoE user name and
password.
Starting IP:
_____._____._____._____
Ending IP:
_____._____._____._____
Netmask:
_____._____._____._____
Default
Route:
_____._____._____._____
DNS IP:
_____._____._____._____
DHCP server
The DFL-1000 NPG contains a DHCP server that you can configure to automatically set the
addresses of the computers on your internal network.
DMZ interface
Use DMZ interface (Optional) to record the IP address and netmask of the DFL-1000 DMZ interface if you
are configuring it during installation.
.
DMZ interface (Optional)
DMZ IP:
_____._____._____._____
Netmask:
_____._____._____._____
Using the setup wizard
From the web-based manager, you can use the setup wizard to create the initial configuration of your
DFL-1000 NPG. To connect to the web-based manager, see Connecting to the web-based manager
.
Starting the setup wizard
• Select Easy Setup Wizard (the middle button in upper-right corner of the web-based manager).
• Use the information that you gathered in NAT/Route mode settings
to fill in the wizard fields. Select
the Next button to step through the wizard pages.
• Confirm your configuration settings and then select Finish and Close.
If you use the setup wizard to configure internal server settings, the DFL-1000 NPG adds port forwarding virtual
IPs and firewall policies for each server that you configure. For each server located on your internal network the
DFL-1000 adds an Ext
->
Int policy. For each server located on your DMZ network, the DFL-1000 NPG adds
an Ext
->
DMZ policy.
Reconnecting to the web-based manager
If you changed the IP address of the internal interface using the setup wizard, you must reconnect to the
web-based manager using a new IP address. Browse to https:// followed by the new IP address of the
internal interface. Otherwise, you can reconnect to the web-based manager by browsing to
https://192.168.1.99.
You have now completed the initial configuration of your DFL-1000 NPG, and you can proceed to connect
the DFL-1000 NPG to your network using the information in Connecting to your networks
.
