DFL-1000 User Manual
13
2
Administration
This chapter describes how to use the web-based manager to administer and maintain the DFL-1000
NPG. It contains the following sections:
•
System status
•
Upgrading the DFL-1000 firmware
•
Displaying the DFL-1000 NPG serial number
•
Backing up system settings
•
Restoring system settings
•
Restoring system settings to factory defaults
•
Changing to Transparent mode
•
Changing to NAT/Route mode
•
Restarting the DFL-1000 NPG
•
Shutting down the DFL-1000 NPG
•
System status monitor
• Network configuration
• Configuring the internal interface
• Configuring the external interface
• Configuring the dmz interface
• Configuring the management interface (Transparent mode)
• Setting DNS server addresses
• Configuring routing
• Adding routing gateways
• Adding a default route
• Adding routes to the routing table
• Configuring the routing table
•
Enabling RIP server support
•
Adding routes (Transparent mode)
•
Configuring the DFL-1000 NPG for multiple Internet connections
•
Providing DHCP services to your internal network
•
System configuration
•
Setting system date and time
•
Changing web-based manager options
•
Adding and editing administrator accounts
•
Configuring SNMP
System status
If you log into the web-based manager using the admin administrator account, you can go to System >
Status to make any of the following changes to DFL-1000 NPG system settings:
•
Upgrading the DFL-1000 firmware
•
Backing up system settings
