DFL-1000 User Manual
91
The destination address is the Internet IP address of the remote client.
•
Select OK to save the destination address.
Adding an encrypt policy for a remote client
Use the following procedure to add an encrypt policy for the remote client shown in Example VPN
between a main office internal network and a remote client.
Example VPN gateway policy configuration
Field name Policy information
Source
Main_Office
Destination
VPN_Client
Service
Any
Action
Encrypt
VPN Tunnel Name
Client_VPN
Allow Inbound
Select
Allow Outbound
Do not select
Inbound NAT
Do not select.
Outbound NAT
Do not select.
To add the encrypt policy:
• Go to Firewall > Policy .
•
Select Int -> Ext.
•
Set Source and Destination to Source and Destination shown in Example VPN gateway policy
configuration.
•
Set Action to ENCRYPT.
Service is set to ANY and cannot be changed.
•
Set VPN Tunnel to Client_VPN.
• Configure the ENCRYPT parameters using the information in Example VPN gateway policy
configuration.
•
Select Allow Inbound to allow the client to connect to the source address.
Only select Allow Outbound if you want users at the destination address to be able to connect to the
client.
•
You can also select Log Traffic and Web filter for encrypt policies.
•
Select OK to save the policy.
Configuring the IPSec VPN client
The VPN client must be running industry-standard IPSec AutoIKE key VPN client software, such as the
D-Link Remote VPN Client.
Configure the client as required to connect to the DFL-1000 VPN gateway using an IPSec VPN
configuration. Make sure that the client configuration matches the DFL-1000 remote gateway and VPN
tunnel configuration, including the settings in Example remote VPN client configuration
.
Example remote VPN client configuration
Field name
DFL-1000 VPN gateway information
Client
information
Remote Gateway
The external IP address of the DFL-1000 VPN gateway. 1.1.1.1
