DFL-1000 User Manual
11
3
Web content filtering
Use DFL-1000 web content filtering for:
•
Enabling web content filtering
•
Blocking web pages that contain unwanted content
•
Blocking access to URLs
•
Removing scripts from web pages
•
Exempting URLs from content or URL blocking
Enabling web content filtering
Enable web content filtering by selecting the Web filter option in firewall policies that allow HTTP
connections through the DFL-1000 NPG. Next, configure web content filtering settings to control how the
DFL-1000 NPG applies web content filtering to the HTTP traffic allowed by policies.
To enable web content filtering:
•
Go to Firewall > Policy .
•
Select a policy list that contains policies for which you want to enable web content protection.
•
Select New to add a new policy, or choose a policy to edit and select Edit
.
The policy must have Service set to ANY, HTTP, or a service group that includes HTTP.
See Adding NAT/Route mode policies
or Adding Transparent mode policies.
• Select Web filter to enable web content filtering protection for this policy. Select show settings to view
the current web content filtering configuration.
•
Select OK to save the policy.
• Repeat this procedure for any HTTP policies for which to enable web content filtering.
Blocking web pages that contain unwanted content
Block web pages that contain unwanted content by selecting Web Filter in firewall policies, enabling
content blocking, and then creating a list of banned words and phrases. When the DFL-1000 NPG blocks
a web page, the user who requested the blocked page receives a block message and the DFL-1000 NPG
writes a message to the event log.
You can add banned words to the list in many languages using Western, Simplified Chinese, Traditional
Chinese, Japanese, or Korean character sets.
This section describes:
•
Enabling the banned word list
•
Changing the content block message
•
Adding words and phrases to the banned word list
•
Temporarily disabling the banned word list
•
Temporarily disabling individual words in the banned word list
•
Clearing the banned word list
• Backing up the banned word list
• Restoring the banned word list
