DFL-1000 User Manual
15
5
You can download copies of these MIB files from D-Link.
Example DFL-1000 MIB fields
Branch Definitions
Firewall
Policy
Address
Service
Schedule
User
Virtual IP
IP/Mac Binding
Status
Operation Mode
Firmware Version
Serial Number
Network
DNS
Routing
DHCP
System
Configuration
VPN
IPSEC
PPTP
L2TP
DFL-1000 traps
The DFL-1000 agent can send traps to up to three SNMP trap receivers on your network that are
configured to receive traps from the DFL-1000 NPG. The DFL-1000 agent sends traps in response to the
events listed in SNMP traps
.
SNMP traps
Event Description
System
Startup
The DFL-1000 NPG starts or restarts.
Invalid
Community
The SNMP agent has received an SNMP request with an invalid community string.
System
Shutdown
The DFL-1000 NPG shuts down.
Agent
Disabled
An administrator has disabled the SNMP agent from the web-based manager. The agent is also
automatically disabled before a system shutdown, and a trap is sent when this occurs.
Agent Enabled
An administrator has enabled the SNMP agent from the web-based manager. The agent is also
automatically enabled when the system starts up.
