DFL-1000 User Manual
11
6
Restoring the banned word list
You can create or edit a banned word list in a text file and upload it from your management computer to
the DFL-1000 NPG.
Each banned word or phrase must appear on a separate line in the text file. Use ASCII and western
language characters only.
All words are enabled by default. You can optionally follow the word with a space and a 1 another space
and a 0 (zero) to enable it and to indicate western language characters.
Sample banned word list text file
Banned 1 0
Banned+phrase+1 1 0
“banned phrase 2” 1 0
To restore the banned word list:
•
Go to Web Filter > Content Block .
• Select Restore Banned Word list
.
• Enter the path and filename of your banned word list text file or select Browse and locate the file.
• Select OK to upload the banned word list backup text file.
• Select Return to display the restored banned word list.
Blocking access to URLs
To block access to URLs, enable URL blocking and then create a list of URLs to be blocked. You can
block all pages on a website by adding its top-level URL or IP address. Alternatively, you can block
individual pages on a website by including the the full path and filename of the web page to block.
When the DFL-1000 NPG blocks a web page, the user who requested the blocked page receives a block
message and the DFL-1000 NPG writes a message to the event log.
This section describes:
• Enabling the URL block list
• Changing the URL block message
•
Adding URLs to the URL block list
•
Temporarily disabling the URL block list
•
Temporarily disabling individual URL blocking
•
Clearing the URL block list
•
Downloading the URL block list
•
Uploading a URL block list
Enabling the URL block list
• Go to Web Filter > URL Block .
• Select Enable URL Block to turn on URL blocking.
The DFL-1000 NPG now blocks web pages added to the URL block list.
Changing the URL block message
To customize the message that users receive when the DFL-1000 NPG blocks web pages:
