Q: I am having problems setting up my policies. I cannot add source or destination addresses to

policies.

When setting up policies, it is important to remember that new addresses cannot be entered into the

Destination or Source fields. New addresses must be added to the firewall address lists. The choices

under the Destination and Source menus come directly from the address lists. See Addresses

Q: I want to set up an incoming policy for an FTP server on my internal network.

Providing access to servers on your internal network is explained in the following sections:

• NAT policy for public access to a server

• Routing policy for access to a server from the internal network

• Transparent mode policy for public access to a server

Q: I want to connect to a TELNET/FTP/WEB server across the Internet. If I set the outgoing policy

service field to TELNET/FTP/HTTP, I can't connect.

Try setting the service to ANY. Settings for individual services assume that the standard port for that

service is being used, and only traffic addressed to that port is allowed through. If you are using a non-

standard port, setting individual services will not work. ANY allows traffic to go to all ports.

Schedules

Q: I need a schedule that will allow access to the Internet overnight, from 9:00 pm to 9:00 am. How

can I do this?

Create a recurring schedule with a start time of 9:00 pm and a stop time of 9:00 am. If the stop time is set

earlier than the start time, the stop time will be during next day.

VPN

Q: The client to subnet configuration was working, but now it has shut down and I can't recover it.

How do I get it back again?

This happens when the tunnel is down and the client software thinks it is still connected. To recover you

must disconnect at the client end.

Q. Why can't I bring up the connection in the case of subnet to subnet configuration?

First check that you have set up the proper IPSec policy for this connection. If you have, check that the

authentication keys are the same on the local and remote IPSec gateways. Also check that the remote

gateway address is correct.

Web content filtering

Q: My employees are job hunting on the Internet when they should be working. Is it possible to

block career sites.

See Blocking access to URLs and enter the names of the unwanted sites into the URL block list.

Q: I am worried about dangerous web content so I set the Script Filter options to block all scripts,

Java Applets, ActiveX, and cookies. Now people are complaining that some web sites are

inaccessible or don't work properly.

See Removing scripts from web pages
