DFL-1000 User Manual
94
Adding encrypt policies for dialup VPN
If you are configuring dialup VPN for a network-to-network VPN, use the procedure in Adding an encrypt
policy for a network-to-network VPN. Use the information in Example encrypt policies.
If you are configuring dialup VPN for a remote client, use the procedure in Adding an encrypt policy for a
remote client. Use the information in Example VPN gateway policy configuration.
Configuring remote IPSec VPN gateways for dialup VPN
The remote IPSec VPN gateways must be DFL-1000 IPSec VPN gateways or third-party IPSec VPN
gateways running industry-standard IPSec AutoIKE key VPN software.
Configure the VPN gateway as required to connect to the dialup VPN gateway using an IPSec AutoIKE
key VPN configuration. Use the information in Example remote IPSec VPN gateway configuration
to
configure the gateway.
Example remote IPSec VPN gateway configuration
Field name
DFL-1000 VPN gateway information
Client
information
Remote Gateway
The external IP address of the dialup VPN gateway. 1.1.1.1
Authentication
Key
The gateway authentication key must match the dialup VPN gateway tunnel
authentication key.
ddcHH01887d
Configuring remote IPSec VPN clients for dialup VPN
The VPN client must be running industry-standard IPSec AutoIKE key VPN client software, such as the
D-Link Remote VPN Client.
Configure the client as required to connect to the dialup VPN gateway using an IPSec AutoIKE key VPN
configuration. Use the information in Example remote IPSec VPN client configuration
to configure the
client.
Example remote IPSec VPN client configuration
Field name
DFL-1000 VPN gateway information
Client
information
Remote Gateway
The external IP address of the dialup VPN gateway. 1.1.1.1
DH Group
Should match the VPN tunnel DH Group. 5
Authentication
Key
The client authentication key must match the dialup VPN gateway tunnel
authentication key.
ddcHH01887d
Manual key VPN between two networks
In this example, you configure a manual key VPN between two internal networks. Example VPN between
two internal networks shows this configuration.
Use the following procedures to configure the manual key VPN:
• Configuring the manual key VPN tunnel
• Adding source and destination addresses
• Adding an encrypt policy
