D-Link DFL-1000 [139/168] Configuring the external interface

DFL-1000 User Manual

Configuring the internal interface

Configuring the external interface

Use the following procedures to configure the external interface:

• Configuring the external interface with a static IP address

•

Configuring the external interface for DHCP

•

Configuring the external interface for PPPoE

•

Controlling management access to the external interface

•

Changing the external interface MTU size to improve network performance

Configuring the external interface with a static IP address

• Go to System > Network > Interface .

• For the external interface, select Modify

• Set Addressing mode to Manual.

• Change the IP address and Netmask as required.

• Select OK to save your changes.
