DFL-1000 User Manual
24
Using the command line interface
As an alternative to using the setup wizard, you can configure the DFL-1000 NPG using the command
line interface (CLI). To connect to the CLI, see Connecting to the command line interface (CLI)
.
Configuring the DFL-1000 NPG to run in NAT/Route mode
Use the information that you gathered in NAT/Route mode settings to complete the following procedures.
Configuring NAT/Route mode IP addresses
•
Log into the CLI if you are not already logged in.
•
Set the IP address and netmask of the internal interface to the internal IP address and netmask that
you recorded in NAT/Route mode settings
. Enter:
set system interface internal static ip <IP address> <netmask>
Example
set system interface internal static ip 192.168.1.1 255.255.255.0
•
Set the IP address and netmask of the external interface to the external IP address and netmask that
you recorded in NAT/Route mode settings
.
To set the manual IP address and netmask, enter:
set system interface external static ip <IP address> <netmask>
Example
set system interface external static ip 204.23.1.5 255.255.255.0
To set the external interface to use DHCP, enter:
set system interface external dhcp connection enable
To set the external interface to use PPPoE, enter:
set system interface external pppoe username <user name> password
<password> connection enable
Example
set system interface external pppoe username user@domain.com password
mypass connection enable
• Optionally set the IP address and netmask of the DMZ interface to the DMZ IP address and netmask
that you recorded in DMZ interface (Optional)
. Enter:
set system interface dmz static ip <IP address> <netmask>
Example
set system interface dmz static ip 10.10.10.2 255.255.255.0
• Confirm that the addresses are correct. Enter:
get system interface
The CLI lists the IP address, netmask and other settings for each of the DFL-1000 NPG interfaces as
well as the mode of the external interface (manual, DHCP, or PPPoE).
• Set the default route to the default gateway IP address that you recorded in NAT/Route mode settings
(not required for DHCP and PPPoE). Enter:
set system route number <number> gw1 <IP address>
Example
set system route number 1 gw1 204.23.1.2
You have now completed the initial configuration of your DFL-1000 NPG, and you can proceed to connect
the DFL-1000 NPG to your network using the information in Connecting to your networks
.
