D-Link DFL-1000 [22/168] Nat route mode installation
![D-Link DFL-1000 [22/168] Nat route mode installation](/views2/1045575/page22/bg16.png)
DFL-1000 User Manual
2
2
NAT/Route mode installation
This chapter describes how to install your DFL-1000 NPG in NAT/Route mode. If you want to install the
DFL-1000 NPG in Transparent mode, see Transparent mode installation
.
This chapter includes:
•
Preparing to configure NAT/Route mode
•
Using the setup wizard
•
Using the command line interface
• Connecting to your networks
• Configuring your networks
• Completing the configuration
Preparing to configure NAT/Route mode
Use NAT/Route mode settings to gather the information that you need to customize NAT/Route mode
settings.
NAT/Route mode settings
Administrator password:
IP:
_____._____._____._____
Internal interface
Netmask:
_____._____._____._____
IP:
_____._____._____._____
Netmask:
_____._____._____._____
Default Gateway:
_____._____._____._____
Primary DNS Server:
_____._____._____._____
External
interface
Secondary DNS
Server:
_____._____._____._____
Web Server:
_____._____._____._____
SMTP Server:
_____._____._____._____
POP3 Server:
_____._____._____._____
IMAP Server:
_____._____._____._____
FTP Server:
_____._____._____._____
Internal servers
If you provide access from the Internet to a web server, mail server, IMAP server, or FTP
server installed on an internal network, add the IP addresses of the servers here.
Advanced NAT/Route mode settings
Use Advanced DFL-1000 NAT/Route mode settings to gather the information that you need to customize
advanced DFL-1000 NAT/Route mode settings.
Advanced DFL-1000 NAT/Route mode settings
External
interface
DHCP:
If your Internet Service Provider (ISP) supplies you with an IP address using DHCP, no
further information is required.
