D-Link DFL-1000 [133/168] Upgrading the dfl 1000 firmware
![D-Link DFL-1000 [133/168] Upgrading the dfl 1000 firmware](/views2/1045575/page133/bg85.png)
DFL-1000 User Manual
13
3
•
Restoring system settings
•
Restoring system settings to factory defaults
•
Changing to Transparent mode
•
Changing to NAT/Route mode
•
Restarting the DFL-1000 NPG
•
Shutting down the DFL-1000 NPG
If you log into the web-based manager with any other administrator account, you can go to System >
Status to view the system settings including:
•
Displaying the DFL-1000 NPG serial number
All administrative users can also go to System > Status > Monitor and view DFL-1000 NPG system
status:
• System status monitor
Upgrading the DFL-1000 firmware
D-Link releases new versions of the DFL-1000 firmware periodically. You can save the firmware file on
your management computer and then use one of the following procedures to upgrade the firmware on
your DFL-1000 NPG:
•
Upgrading the firmware using the web-based manager
•
Upgrading the firmware from a TFTP server using the CLI
Upgrading the firmware using the web-based manager
•
Go to System > Status .
• Select Firmware Upgrade
.
• Enter the path and filename of the firmware update file, or select Browse and locate the file.
• Select OK to upload the firmware update file to the DFL-1000 NPG.
The DFL-1000 NPG uploads the file and restarts, running the new version of the firmware.
•
Reconnect to the web-based manager.
•
Go to System > Status and check the Firmware Version to confirm that the updated firmware has
been installed successfully.
Upgrading the firmware from a TFTP server using the CLI
Use the following procedure to upgrade the DFL-1000 firmware using the CLI. To use this procedure,
you must install a TFTP server and be able to connect to this server from the internal interface. The
TFTP server should be on the same subnet as the internal interface.
Installing new firmware using the CLI deletes all changes that you have made to the configuration and reverts
the system to its default configuration, including resetting interface addresses. To keep your current settings,
before installing new firmware, download your configuration file (see Backing up system settings
) and your web
content and URL filtering lists (see Backing up the banned word list
, Downloading the URL block list, and
Downloading the Exempt URL list
).
Upgrading the firmware
To install a firmware upgrade using the CLI:
• Connect to the CLI.
• Make sure that the TFTP server is running.
• Copy the new firmware image file to the root directory of your TFTP server.
