DFL-1000 User Manual
2
9
Configure the Transparent mode default gateway
• Log into the CLI if you are not already logged in.
• Set the default route to the default gateway that you recorded in Transparent mode settings
. Enter:
set system route number <number> gateway <IP address>
Example
set system route number 1 gateway 204.23.1.2
You have now completed the initial configuration of the DFL-1000 NPG, and you can proceed to the next
section.
Setting the date and time
For effective scheduling and logging, the DFL-1000 NPG date and time should be accurate. You can
either manually set the time or you can configure the DFL-1000 NPG to automatically keep its time
correct by synchronizing with a Network Time Protocol (NTP) server.
To set the DFL-1000 NPG date and time, see Setting system date and time
.
Connecting to your networks
When you have completed the initial configuration, you can connect the DFL-1000 NPG between your
internal network and the Internet. You can also connect a network to the DMZ interface.
There are three 10/100Base-TX connectors on the DFL-1000 NPG:
•
Internal for connecting to your internal network
•
External for connecting to the Internet
•
DMZ for connecting to another network
To connect the DFL-1000 NPG running in Transparent mode:
Connect the Internal interface to the hub or switch connected to your internal network.
•
Connect the DMZ interface to another network.
