DFL-1000 User Manual
12
0
website runs a story on pornography, web pages from the reputable website would be blocked. Adding
the address of the reputable website to the Exempt URL list allows the content of the website to bypass
content blocking.
This section describes:
• Adding URLs to the Exempt URL list
• Temporarily disabling entries in the Exempt URL list
• Clearing the Exempt URL list
• Downloading the Exempt URL list
• Uploading an Exempt URL list
Adding URLs to the Exempt URL list
• Go to Web Filter > Exempt URL .
• Select New to add an entry to the Exempt URL list.
• Type the URL to exempt.
Enter a complete URL, including path and filename, to exempt access to a page on a website. For
example, www.goodsite.com/index.html exempts access to the main page of this example
website. You can also add IP addresses; for example, 122.63.44.67/index.html exempts
access to the main web page at this address. Do not include
http://
in the URL to exempt.
Exempting a top-level URL, such as www.goodsite.com, exempts all requested subpages (for
example,
www.goodsite.com
/
badpage
) from all content and URL filtering rules.
Exempting a top-level URL does not exempt pages such as mail.goodsite.com from all content and URL
filtering rules unless
goodsite.com
(without the
www
) is added to the Exempt URL list.
•
Select Enable to exempt the URL.
•
Select OK to add the URL to the Exempt URL list.
You can enter multiple URLs and then select Check All
to activate all entries in the Exempt URL
list.
Each page of the Exempt URL list displays 100 URLs.
• Use Page Down
and Page Up to navigate through the Exempt URL list.
