DFL-1000 User Manual
6
8
Normally an AutoIKE key VPN tunnel requires one remote gateway. This can be a gateway with a static IP
address or a dialup gateway. For IPSec redundancy, you can add up to three remote gateways with static IP
addresses to an AutoIKE key tunnel. For information about IPSec redundancy, see Configuring IPSec
redundancy.
To create an AutoIKE key VPN configuration:
•
Add a remote gateway.
See Adding a remote gateway
.
• Add an AutoIKE key VPN tunnel that includes the remote gateway that you added in step 1.
See Adding an AutoIKE key VPN tunnel
.
•
Add an encrypt policy that includes the tunnel, source address, and destination address for both ends
of the tunnel.
See Adding an encrypt policy
.
For an example AutoIKE key configuration between two networks, see AutoIKE key VPN between two
networks.
For an example AutoIKE key configuration for remote clients, see AutoIKE key VPN for remote clients
.
Configuring manual key IPSec VPN
A manual key VPN configuration consists of a manual key VPN tunnel, the source and destination
addresses for both ends of the tunnel, and an encrypt policy to control access to the VPN tunnel.
To create a manual key VPN configuration:
• Add a manual key VPN tunnel.
See Adding a manual key VPN tunnel
.
•
Add an encrypt policy that includes the tunnel, source address, and destination address for both ends
of the tunnel.
See Adding an encrypt policy
.
For an example manual key configuration between two networks, see Manual key VPN between two
networks.
For an example manual key configuration for remote clients, see Manual key VPN for remote clients
.
Configuring dialup VPN
Use a dialup VPN configuration to allow remote clients or VPN gateways with dynamic IP addresses to
connect to a DFL-1000 VPN gateway. Clients or gateways with dynamic IP addresses can be home or
travelling users who dial into the Internet and are dynamically assigned an IP address by their ISP (using
PPPoE, DHCP, or a similar protocol).
A dialup VPN configuration consists of a remote gateway and one or more VPN tunnels for this remote
gateway. For each VPN tunnel, you must add an encrypt policy to control access to the VPN tunnel.
Dialup VPN has several configurations for user authentication. For information about dialup VPN
authentication, see About dialup VPN authentication
.
To create a dialup VPN configuration:
• Add a remote gateway and select Dialup User.
See Adding a remote gateway
.
